Dimensions :

DIMENSIONS
Tare weight		11000kg		Payload		60000kg
Overall Length	10950mm		Overall Width	2500mm	Overall height	3620mm

Specification :

SPECIFICATION
Chassis	Heavy duty and extra durability designed i beam；opting for high tensile steel Q345，welded by automatic subrnerged-Arc processes. Top flange 18mm，width 140mm；Middle Flange 10mm；bottom flange20mm，width 140mm
Axle	Number	3	Brand	Optional upon choice	Capacity	13T
Suspension	Mechanical suspension Or air suspension
Leaf spring	Leaf spring or air bag
Floor	8mm plate.side wall 6mm
Tire	11.00R20，12.00R20，11R22.5，12R22.5，315/80R22.5 Tire optional
Wheel rim	8.5-20，9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice
Kingpin	2”/3.5”bolt-in king pin
Landing gear	JOST brand two-speed，manual operation，heavy duty landing gear
Cylinder	HYVA
Braking system	WABCO RE6 relay valve；T30/30 sping brake chamber；40L air tanks
Painting	Complete chassis sand blasting to clean rust，1coat of anticorrosive prime，2coats of final paint
Accessories	One standard tool box

If you have any question or demand of trucks ,pls kindly contact us.
