Dimensions :

DIMENSIONS

Tare  weight

10000kg

Payload

50000kg

Overall  Length

13000mm

Overall  Width

2550mm

Overall height

3400mm

SPECIFICATION

Chassis

Heavy duty and extra durability designed i beam；opting for high  tensile steel Q345，welded by automatic subrnerged-Arc processes. Top flange 16mm，width 200mm；Middle Flange 8mm；bottom flange16mm，width 200mm

Axle

Number

3

Brand

Optional upon choice

Capacity

13T

Suspension

Mechanical suspension Or air suspension

Leaf spring

Leaf spring or air bag

Floor

3mm bottom plate.side wall 2mm

Tire

11.00R20，12.00R20，11R22.5，12R22.5，315/80R22.5 Tire optional

Wheel rim

8.5-20，9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice

Kingpin

2”/3.5”bolt-in king pin

Landing gear

JOST brand two-speed，manual operation，heavy duty landing gear

Vehicular applications

Cargos transport

Braking system

WABCO RE6 relay valve；T30/30 sping brake chamber；40L air tanks

Painting

Complete chassis sand blasting to clean rust，1coat of anticorrosive prime，2coats of final paint

Accessories

one standard tool box
