Dimensions :

DIMENSIONS

TARE WEIGHT

11000KG

PAYLODA

40000KG

 overall

 12000mm

overall width

 2500mm

overall height

4000mm

SPECIFICATION

 TANK body

q235a/6mm steel  sheet     shape：V type

     END PLATE

q235a/6mm. ball shape

     AXLE

number

3

brand

optional upon choice

capacity

13t

suspension

mechanical suspension or Air suspension

    leaf spring

 leaf spring or Air  bag

    manhole cover

500mm manhole cover .2sets

    tire

11.00r20，12.00r20，11r22.5，315/80r22.5 tire optional

    wheel rim

8.5-20,8.25-20,9.0-22.5,steel wheel rim optional upon choice

   discharge valve

4''disc valve

   dischargepipe

4''seamless steel tube

   kingpin

2''/3.5''bolt-in kingpin

   landinggear

jostbrandtwo-speed， manualoperating，heavy duty landing gear

   engine

diesel engine or electrical  motor

   air compressor

37 kw，0.2mpa.100r/min

   compartment

single

   braking system

wabco re6 reay valve：t30/30spring brake chamber：40l air tanks

   painting

complete chassis sand blasting to clean rust，1cpat of anticorrosive prime， 2coats of final paint

   accessories

one standard tool box

   air-charging system

2''main hole，2''checkvalve，1.5''safe valve，0.4map gauge

   quadratic blow

1''diameter check valve

   qutlet discharge pipe

4''rubber hose.6m
