2015-10-19 10:43:29
|
NO. |
Part No. |
Chinese Name |
Part Name |
|
1 |
DZ95259521411 |
前簧前支架 |
Front Leaf
-spring Bracket |
|
2 |
Q33010T13F2 |
全金属六角法兰面锁紧螺母 |
Hex locked-metal
nut with frange |
|
3 |
Q150B1090TF2 |
六角头螺栓 |
Hexagon Bolt |
|
4 |
81.41304.0053 |
轴套 |
Bush |
|
5 |
81.43402.6142 |
前板簧总成 |
Front
Leaf-spring Assembly |
|
81.43402.6115 |
前板簧总成 |
Front
Leaf-spring Assembly |
|
|
6 |
06.11289.0003 |
台肩螺母 |
Nut |
|
7 |
06.02839.0021 |
六角头螺栓M24*2*160 |
Hex Bolt
M24*2*160 |
|
81.90490.0622 |
螺栓 |
Bolt |
|
|
8 |
81.96020.6013 |
空心橡胶缓冲块 |
Cushion Rubber |
|
9 |
81.43640.5102 |
支架总成 |
Bracket Assembly
|
|
10 |
81.43740.0152 |
角支架 |
Bracket |
|
11 |
81.96020.6013 |
空心橡胶缓冲块 |
Cushion Rubber |
|
12 |
81.43640.5101 |
支架总成 |
Bracket Assembly
|
|
13 |
81.41303.0079 |
板簧连接板(带螺纹) |
Leaf-spring
Connecting |
|
Panel ( with
thread) |
|||
|
14 |
DZ95259521185 |
前簧骑马螺栓 |
Saddle Clamp
Bolt |
|
DZ95259521230 |
前簧骑马螺栓 |
Saddle Clamp
Bolt |
|
|
DZ9100526015 |
前簧骑马螺栓 |
Saddle Clamp
Bolt |
|
|
15 |
81.41335.0084 |
弹簧夹紧板 |
Spring Clamp
Plate |
|
16 |
DZ95259521275 |
前簧骑马螺栓 |
Saddle Clamp
Bolt |
|
DZ95259521320 |
前簧骑马螺栓 |
Saddle Clamp
Bolt |
|
|
DZ9100526016 |
前簧骑马螺栓 |
Saddle Clamp
Bolt |
|
|
17 |
DZ9114526025 |
弹簧座 |
Spring Seat |
|
18 |
DZ9114526024 |
导向销 |
Guidd Pin |
|
19 |
81.41303.0080 |
板簧连接板(不带螺纹) |
Leaf-spring
Connecting Plate (without thread) |
|
20 |
06.02839.0012 |
六角头螺栓M24*2*140 |
Hex Bolt M24*2*140
|
|
21 |
81.41301.6111 |
前板簧后支架总成(左件) |
Rear Bracket
Assembly (Left) |
|
|
81.41301.6110 |
前板簧支架总成(右件) |
Bracket Assembly
(Right) |
|
|
DZ9114526270 |
前簧左后支架总成 |
Rear Bracket
Assembly (Left) |
|
|
DZ9114526273 |
前簧右支架总成 |
Bracket Assembly
(Right) |
|
22 |
Q1811460T
|
六角法兰面承面带齿螺栓 |
Hex bolt with flange & teeth |
|
|
Q1811440T
|
六角法兰面承面带齿螺栓 |
Hex bolt with flange & teeth |
|
|
06.11251.2005 |
六角自锁螺母 |
Hex Self-locking Nut |
|
23 |
|
M14X1.5-10-MAN183-B1 |
|
|
|
Q1811440T
|
六角法兰面承面带齿螺栓 |
Hex bolt with flange & teeth |
|
24 |
06.11251.2005 |
六角自锁螺母 |
Hex Self-locking Nut |
|
25 |
|
M14X1.5-10-MAN183-B1 |
M14X1.5-10-MAN183-B1 |
|
|
Q1811440T
|
六角法兰面承面带齿螺栓 |
Hex bolt with flange & teeth |
|
26 |
06.11251.2005 |
六角自锁螺母 |
Hex Self-locking Nut |
|
27 |
|
M14X1.5-10-MAN183-B1 |
