Dimensions :

Tare weight		15000kg		Payload		60000kg
Overall Length	11000mm		Overall Width	2500mm	Overall height		3500mm

Specification :

SPECIFICATION
Chassis	Heavy duty and extra durability designed i beam；opting for high tensile steel Q345，welded by automatic subrnerged-Arc processes. Top flange 16mm，width 200mm；Middle Flange 8mm；bottom flange16mm，width 200mm
Axle	Number	3	Brand	Optional upon choice	Capacity	13T
Suspension	Mechanical suspension Or air suspension
Leaf spring	Leaf spring or air bag
Floor	3mm bottom plate.side wall 2mm
Tire	11.00R20，12.00R20，11R22.5，12R22.5，315/80R22.5 Tire optional
Wheel rim	8.5-20，9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice
Kingpin	2”/3.5”bolt-in king pin
Landing gear	JOST brand two-speed，manual operation，heavy duty landing gear
Vehicular applications	Cargos transport
Braking system	WABCO RE6 relay valve；T30/30 sping brake chamber；40L air tanks
Painting	Complete chassis sand blasting to clean rust，1coat of anticorrosive prime，2coats of final paint
Accessories	one standard tool box

If you have any question or demand of trucks ,pls kindly contact us.
